Side-Pull Battery Cases

Side-pull e-bike battery cases for 20-80 cells — dual 18650/21700 compatibility, aluminum + PC/ABS, mechanical key lock, DC2.1 charge port, up to 10S8P layouts.

Brand: MotorEnable
Cell compatibility: 18650 / 21700
Material: Aluminum alloy / PC+ABS
Application: Side-release downtube e-bike packs, 10S-13S layouts

Side-pull release for frames where top or down removal is blocked
Dual-format cell cradles accept 18650 or 21700 cells
Up to 80 × 18650 cells (10S8P) in the largest case
Aluminum alloy shell with PC+ABS end caps
Mechanical key lock on all models
DC2.1 charge port, 6/7-pin discharge connectors

Get a Quote

Side-pull battery enclosures release sideways out of the frame — the layout of choice when a rear rack, child seat or frame geometry blocks vertical removal. All three sizes take either 18650 or 21700 cells, and the largest SSE-144 reaches 10S8P (80 cells) for high-capacity touring and cargo packs.

These are wholesale, quote-only enclosures (case only — no cells or BMS included). Tell us your cell format, series/parallel layout and frame clearance and we’ll confirm the matching model and pricing.

Models & specifications

Model	Max cells	Layouts (18650 / 21700)	Charge port	Discharge	Lock	Gauge
SSE-144	80 × 18650 / 65 × 21700	10S8P, 13S6P / 13S5P, 10S6P	DC2.1	7-pin	Mechanical lock	3-level LED
SSE-145	52 × 18650 / 30 × 21700	10S5P, 13S4P / 10S3P	DC2.1	6-pin	Mechanical lock	Single LED (3-color)
SSE-146	40 × 18650 / 20 × 21700	10S4P, 13S3P / 10S2P	DC2.1	6-pin	Mechanical lock	Single LED (3-color)

All models: aluminum alloy shell with PC+ABS end caps.

Highlights

Side release: removes laterally, clearing racks, seats and tight frame triangles.
Dual cell format: the same case builds as an 18650 or 21700 pack.
Up to 80 cells: the SSE-144 covers high-capacity 10S8P builds for touring and cargo bikes.
